Full Automatic Gypsum Ceiling Tile Production Line with 1300mm Effective Laminating and 2-6 Million Sq.m/year Capacity

Full Automatic Gypsum Ceiling Tile Production Line with 1300mm Effective Laminating and 2-6 Million Sq.m/year Capacity

نام تجاری:	LVJOE
شماره مدل:	1300FM
مقدار تولیدی:	1 خط
قیمت:	US $20000-200000
شرایط پرداخت:	L/C ، T/T
توانایی عرضه:	10 خط در سال

اطلاعات دقیق

توضیحات محصول

اطلاعات دقیق

محل منبع:

هبی ， چین (سرزمین اصلی)

گواهی:

ISO CE

نام محصول:

دستگاه لمینیت دو طرفه پیشرفته تمام اتوماتیک دستگاه ساخت کاشی سقف تخته گچی

کلمه کلیدی:

ماشین ساخت کاشی های سقف گچ

نوع صفحه تمام شده:

تخته گچ لمینت PVC

لمینیت موثر:

1300 میلی متر

کنترل برقی:

سیستم PLC

ظرفیت تولید:

2-6 میلیون متر مربع در سال

سرویس پس از فروش:

مهندسان موجود در خدمت

نوع چسب:

چسب آب برای فیلم PVC

جزئیات بسته بندی:

بسته بندی استاندارد

قابلیت ارائه:

10 خط در سال

برجسته کردن:

1300mm Effective Laminating Gypsum Ceiling Tile Production Line,2-6 million Sq.m/year Production Capacity Gypsum Board Laminating Machine,Adjustable Speed 2-15m/min PVC Laminated Gypsum Board Machine

2-6 million Sq.m/year Production Capacity Gypsum Board Laminating Machine

Adjustable Speed 2-15m/min PVC Laminated Gypsum Board Machine

توضیحات محصول

Full Automatic Advanced Double Side Laminating Machine for Gypsum Board Ceiling Tiles

Product Overview

This advanced double side laminating machine is designed for producing PVC laminated gypsum boards used as ceiling tiles and partition wall panels. The fully automatic system handles fiber glass, paper, PVC film, and aluminum foil lamination with precision and efficiency.

Key Specifications

Attribute	Value
Finished board type	PVC laminated gypsum board
Effective laminating width	1300mm
Electric control	PLC system
Production Capacity	2-6 million Sq.m/year
Speed	2-15m/min (adjustable)
After-sales Service	Engineers available to service
Warranty	1 year
Glue type	Water Glue for PVC film

Main Components

Automatic Gypsum Board Feeding Machine

The cylinder pushes gypsum boards from the stack lift platform to the conveyor roll for PVC and aluminum film lamination.

Max. Load-bearing: 3000kg

Stroke: 1500mm

Height range: 620mm - 2000mm

Platform size: 1200×2400mm

Automatic Cutting Machine

Features two cutting systems (vertical/longitudinal and horizontal) with dust collection, converting 1.2×2.4m boards into 603×603mm or 595×595mm tiles.

Cutting speed: 15m/min

Cutting knives: Vertical: 3 blades, Horizontal: 5 blades

Overall power: 17.15KW

Technical Specifications

Sheet thickness range: 5-30mm
Speed adjustment: Frequency conversion synchronous speed regulating
Annual capacity: 2-4 million Sq.m
Compatible film materials: PVC film, aluminum foils, decorative materials
Board materials: PVC baseboard, gypsum board, wood board, sectional board, PVC foam board
Stacking mode: 10 layers (4 packages/layer)
Lamination options: Double side (front and back simultaneously) or single side
Overall dimensions: 56000mm (L) × 9200mm (W)
