PLC Control Dust Collector for 380V Automatic Rock Wool Production Line

PLC Control Dust Collector for 380V Automatic Rock Wool Production Line

نام تجاری:	Greens
مقدار تولیدی:	1
قیمت:	US $2000000-4000000
شرایط پرداخت:	L/C، T/T

اطلاعات دقیق

توضیحات محصول

اطلاعات دقیق

محل منبع:

هبی

نام محصول:

جمع آوری گرد و غبار برای دستگاه خط تولید تخته فیبر سنگ / سنگ / پشم معدنی

کلمه کلیدی:

تجارت خط تولید پشم راک

رنگ:

انتخاب کنید

ولتاژ:

380 ولت یا سفارشی

کنترل برقی:

کنترل PLC

وضعیت:

جدید

مواد خام:

بازالت، سرباره، دولومیت

کوره احتراق:

کوره گاز طبیعی یا کوره برقی

برجسته کردن:

PLC Control Dust Collector,380V Rock Wool Production Line,Automatic Mineral Wool Board Production Line

380V Rock Wool Production Line

Automatic Mineral Wool Board Production Line

توضیحات محصول

Dust Collector For Rock/Stone/Mineral Wool Fiber Board Production Line Machine

Rock wool products are manufactured from high-quality basalt and dolomite raw materials. Through high-temperature melting and high-speed centrifugation using four-axis centrifuges, these materials are transformed into fibers. During this process, binders, dustproof oils, and water repellents are applied. The fibers are collected, cured, and cut using pendulum and three-dimensional laying methods to create rock wool products in various specifications. As artificial inorganic fibers processed at high temperatures, rock wool offers lightweight properties, low thermal conductivity, excellent insulation, and flame retardancy, making it widely applicable across multiple industries.

Mineral Wool Production Line Process & Equipment

Melting Furnace Types: Electric furnace (environmentally friendly with high controllability, ideal for premium products) and Cupola furnace (cost-effective with stringent environmental requirements)
Automation Level: Features automatic batching, pendulum cotton laying, online cutting, and palletizing/baling systems to minimize labor costs and material waste
Environmental Protection: Comprehensive systems including desulfurization, denitrification, bag-type dust removal, and VOCs treatment to meet local emission standards

Technical Specifications

Product Name	Rock Wool Production Line
Automation Grade	Automatic
Voltage	380V
Features	Automatic Operation
Panel Thickness	30-200mm
Felt Size	1000mm (adjustable)
Panel Density	30-200 Kg/m³
Applicable Industries	Manufacturing Plant, Retail, Construction Works
Finished Products	Rock Wool Board
Usage	Building Material Production
